The new Stewart Luxus Electriscreen is an appealing compact, below ceiling retractable screen system that is ideal for image widths up to 15 feet 2 inches. With a 12 inch black drop, the new Luxus is 3/4 of an inch smaller in circumference and features a mounting bracket that allows the screen case to slide horizontally for proper centering on the wall or ceiling. The new Luxus now has a 3.5mm input, built in IR w/a 3.5mm built in 12v trigger. The older Luxus G1 had a built in 12v trigger that was a complex RJ 45 input, and did not come with IR. If you wanted IR added to the previous model, a bulky box would need to ship separately. With the new model/upgrade, it’s now all buried into one with the all-new 3.5mm input jack. The housing has both wall or ceiling mount into one design. The chassis is different than the old model too. With built-in controls and a removable case bonnet, the new Luxus continues to be a well proven screen with a time-tested following.

*It is important to add only the amount of black drop needed. Side and bottom masking determined by the amount of black drop and image size.

More style. More convenience. More affordable

Beyond stunning, Stewart’s all new Luxus retractable screen system now brings the next level of industry-leading innovation to the two-piece projection screen market.

Way cool mounting bracket

Installation is easier, faster and more convenient. The new Luxus uses a sliding mounting bracket which runs along both the top and back of the case for a perfect wall or ceiling fit. The new Luxus is also ¾ of an inch smaller in circumference, making the screen case more compact.

New multi-platform controller that speaks IR, Serial, RF, IP, Trigger and Dry Contact

The Intelligent Motor Control (IMC) 100 is a highly reliable multi-platform friendly solution that is fully hidden and integrated into the screen case. Access to the screen assembly, motor and the control is now easier with the removable case bonnet.

Built to impress

The end caps come standard in black or white to match the screen case or, you can choose optional hand-polished billet aluminum end caps to take the screen to a whole new level of sophistication.

Plug and Play Access

The new Luxus provides easy and direct access to power and control outputs via the back of the case. The Smart Port allows access to IR, Serial and more.

Standard Features:

• The new Luxus now has a new 3.5mm input, built in IR w/a 3.5mm built in 12v trigger
• Housing has both wall or ceiling mount into one design
• Chassis is different than the old model
• Electronically controlled retractable screen system
• Roller tube with sound-dampening insulated screen drive
• Aluminum extrusion housing/case (choose a black or white finish)
• Available with a variety of Stewart's award winning front and rear projection materials
• Matte black over-scan border* provides for a perfectly masked image area
• Quiet motor technology is offered when silent screen operation is required
• Luxus is available when larger size or reverse roll option is needed
• 12" black drop, custom sizes available*

Review of Stewart Filmscreen Material HTmarket.com review's Stewart StudioTek 130, Firehawk G3 and Ultramatte 150 screen fabrics side by side. You can learn which screen material to choose with your Stewart Filmscreen. This video helps you select the proper screen fabric.



Screen Material
FireHawk G5 Engineered for use with 1080p technology Extremely smooth & flat optical surface Enhanced focusing capabilities Superior performance in high ambient light Microperf X² (optional, call for availability)	Gain: 1.1 Half Gain: 35 degrees
StudioTek 130 G4 Industry's standard reference screen JKP & ISF Certified Extremely smooth & flat optical surface Enhanced focusing capabilities 30% brighter than a matte-white screen Microperf X² (optional, call for availability)	Gain: 1.3 Half Gain: 80 degrees
GrayHawk RS G4 Call for Pricing Industry's first gray reference screen JKP & ISF Certified Extremely smooth & flat optical surface Enhanced focusing capabilities Neutral density gray for added contrast Microperf X² (optional, call for availability)	Gain: 0.9 Half Gain: 75 degrees
StudioTek 100 Call for Pricing Matte-white screen Unity gain reference Extremely wide angle of view Microperf X² (optional, call for availability)	Gain: 1.0 Half Gain: Full Lambertian Diffuser
Phantom HALR Call for Pricing Only black screen on the market that can be perforated for acoustical transparency Available in any image size up to 40 feet by 90 feet High ambient light rejection screen Not susceptible to color shift Microperf X² (optional, call for availability)	Gain: 1.0 Half Gain: 30 degrees
GrayMatte 70 Call for Pricing Neutral density matte gray surface Excellent for edge-blending applications Dampens cross refection in curved installs Microperf X² or Cinemaperf (optional, call for availability)	Gain: 0.7 Half Gain: Full Lambertian Diffuser
Snomatte 100 Call for Pricing Matte-white screen Unity gain reference Extremely wide angle of view Microperf X² or Cinemaperf (optional, call for availability)	Gain: 1.0 Half Gain: Full Lambertian Diffuser
UltraMatte 130 Call for Pricing 30% brighter than matte-white screens Wide viewing angle for off axis seating Great for large venue applications Microperf X² or Cinemaperf (optional, call for availability)	Gain: 1.3 Half Gain: 80 degrees
UltraMatte 150 Call for Pricing 50% brighter than matte-white screens Higher gain for low output projector Great for large venue applications Microperf X² or Cinemaperf (optional, call for availability)	Gain: 1.5 Half Gain: 61 degrees

Why Microperf X² is the industry's #1 choice for acoustically transparent material:

• Available with any of Stewart's front projection materials (excluding Silver 3D)
• First projection material to be THX Ultra Certified
• Impeccable image fidelity
• Unbeatable audio quality (no secondary black backing is required)
• Exceptional contrast, color saturation, and uniformity
• Moiré pattern is eliminated
• Significantly less light return/blow-through
• Largest seamless acoustically transparent screen available (maximum material O.D. is 14-1/2 ft by 60 ft)

Why choose CinemaPerf for your acoustically transparent solution:

• Available with a variety of Stewart's front projection materials
• Excellent for use in large venue installations where an acoustically transparent screen is required
• Unbeatable image fidelity and audio quality (no secondary black backing is required)
• Exceptional contrast, color saturation, and uniformity
• No Moiré pattern
• Case measures 6.875" high and 6.25" deep; see table below for length.

Ready to Order Screen Options

Diagonal	Image Size
100"	49" x 87"
110"	54" x 96"
120"	58.75" x 104.5"
123"	60" x 107"
135"	66" x 118"
150"	73.5" x 130.75"

Custom Screen Sizes and Materials (Call for Pricing)

Diagonal	Image Height	Image Width	Screen Height	Screen Width	Case Width
82"	40 ¼"	71 ½"	55 ¾"	83 ½"	92 ¼"
92"	45 ⅛"	80 ⅛"	60 ⅝"	92 ⅛"	100 ⅞"
106"	52"	92"	67 ½"	104"	112 ¾"
